| Process Fluid: |
Display: |
| Liquid, Gas or Vapor |
5 Digits programmable & 0-100% Bargraph |
| Application: |
Display Unit: |
| Absolute Pressure, Gauge Pressure, |
Standard 22 different engineering unit |
| Vacuum |
5 Digits programmable for special unit |
| Measuring Range: |
Keyboard: |
| 0 - 10 Kpa ~ 0 - 30 Kpa ( Minimum ) |
3 internal keys for Programming |
| 0 - 32 Mpa ~ 0 - 70 Mpa ( Maximum ) |
and output setting |
| Turndown Ratio: |
Current Output: |
| 1 : 100 |
4 - 20 mA 2 wires with Hart Signal |
| Accuracy: |
Load |
| +/- 0.075% of span |
Rohm=(Vdc-9)*50 |
| Stability: |
Power Supply: |
| +/-0.15% of URL for 2 years |
9 ~ 36 VDC |
| Working Temperature: |
Digital Communication: |
| -25 to +95 oC |
Hart Protocol |
| Max. Pressure: |
Damping: |
| 70 Mpa |
0 - 32 seconds |
| Material: |
Response Time: |
| Connection |
90 mS |
| SUS 304 / SUS 316 |
Mounting: |
| Diaphragm |
Direct installation or bracket on 2" Pipe |
| SUS 316L / Tantalum |
Humidity Limit: |
| Housing |
0 to 100% Relative Humidity |
| Low copper cast aluminum alloy with |
Turn on Time: |
| polyurethane, light blue paint |
2 Seconds with minimum damping |
| Name / Tag Plate |
Zero Calibration: |
| Stainless Steel 304 / Stainless Steel 316 |
Automatic zero calibration by push-button |
| Cable Entry: |
Ambient Temperature: |
| M20 Conduit Threads / 1/2" NPT( Female ) |
-25 to +85 oC |
| Process Connection: |
Dimensions: |
| 1/2" NPT, 1/2" BSP |
102 mm ( W ) * 160 mm ( H ) * 130 mm ( D ) |
| Temperature Effect: |
Weight: |
| +/-0.18% of span per 20 oC |
1.3 Kg |
| Over Pressure Limit: |
Protection Class: |
| 120% of Full Scale |
IP67 ( Standard ) |
| Vibration Effect: |
Intrinsically Safe EEx ia IIC T5 (Standard) |
| +/-0.05% of URL per g to 200 Hz in any |
Explosion proof Ex D IIB T5 |
| axis |
|
| EMI/RFI Effect: |
|
| Follow SAMA PMC 33.1 from 20 to 1000 |
|
| MHz and for field strengths up to 30 V/m |
