| Measuring Principle: |
Keypad: |
| Transit time difference |
16 Key with tactile action |
| Pipe Size: |
Response Time: |
| S Type : 15 mm ~ 100 mm (1/2" ~ 4") |
Less than 1 second |
| M Type : 50 mm ~ 1000 mm (2" ~ 40") |
Flow Velocity: |
| L Type : 300 mm ~ 6000 mm (12" ~ 240") |
0.01 ~ +/- 32 m/s |
| HS Type : 15 mm ~ 100 mm (1/2" ~ 4¡ĄŔ) |
Resolution: |
| HM Type: 50 mm ~ 1000 mm (2" ~ 40¡ĄŔ) |
0.0001 m/s |
| Pipe Material: |
Ambient Temperature: |
| Cast Iron, Stainless Steel, Ductile Iron |
-20 ~ +50 oC |
| Copper, PVC, Aluminum, Fiberglass... etc. |
Mounting: |
| Liner Material: |
Wall mounting |
| Tar Epoxy, Rubber, Mortar, Polypropylene, |
Max. Cable Length: |
| Polystyrol, Polyethylene, Teflon¡ etc |
150 M |
| Display: |
Power Consumption: |
| 4 Line LCD with illumination |
Less than 2W |
| Flowrate |
Power Supply: |
| 5 digit with decimal point |
90 ~ 260Vac 50/60 Hz or 8-36Vdc |
| Totalizer |
Data Storage: |
| 8 digit, Forward, Reverse & Net values. |
Operation parameters and totalizer |
| Engineer Unit |
figures are stored by EEPROM for more |
| M3, Liter, US Gallon, Imperial Gallon, |
than 10 years |
| Million Gallon, Cubic Feet, US Barrels, |
Output: |
| Imperial Barrels, Oil Barrel |
4-20 mA or 0-20 mA |
| Time Unit |
Pulse Output: |
| Second, Minute, Hour, Day |
1- 9999 Hz |
| Other |
Data Logger: |
| Velocity, Date, Time, Signal condition. |
Limitless overwriting in 64 columns |
| Accuracy: |
(Flowrate, totalizer, time, date included) |
| +/- 1% ~ +/- 2% of reading (0.5 ~ 30 m/s) |
Alarm: |
| +/- 0.5% of reading (Online calibration) |
High/Low with buzzer |
| Repeatability: |
Communication: |
| +/-0.2% of reading |
RS-232 |
| Temperature Input: |
Dimensions: |
| 4-20 mA * 2 points for BTU calculation |
235 * 205 * 95 mm |
| Function |
Weight: |
 T, Measurements for Thermal Energy |
1.5 Kg |
| |
Protection Class: |
| |
Converter |
| |
IP65 |
| |
Sensor |
| |
IP68 (Submersible) |
