| Excitation: |
Keyboard: |
| DC pulsed |
3 external keys for programming |
| Display: |
and display control |
| 3 lines LCD with illumination |
Remote switch instead, no need to open |
| Line 1 |
cover |
| 11 digit totalizer for forward flow |
Low Flow Cutoff: |
| 11 digit totalizer for reverse flow |
0 to 9.9 % |
| 11 digit totalizer for difference |
Data logger Function: |
| Line 2 |
99 times flowrate records for power on/off |
| 5 digit flowrate / velocity / % / mA / HZ |
Record Data: |
| Line 3 |
Date/Time when Power on/off |
| Parameter / Query / Clr tot / Query LOG |
Flow rate when Power on/off |
| Alarm, Guidance |
Totalizer when Power on/off |
| Unit |
Damping: |
| M3/H, L/H, Kg/H, T/H, L/min, M3/min, GPH |
0 to 99 Seconds |
| GPM, ML/H, ML/m, ML/sec |
Density Setting: |
| Measuring Range: |
0.1 to 9.99 g/cm3 |
| Min. 0 to 0.15 m/s |
Self Diagnosis: |
| Max. 0 to 15 m/s |
The following error message are |
| Accuracy: |
displayed if failure occurs |
| +/-0.2% read-out values (Velocity >=0.5 m/s) |
- Coil failure |
| +/-0.001 m/s (Velocity < 0.5 m/s) |
- Power failure |
| Repeatability: |
- Overanged Output |
| +/-0.05% read-out values |
- Internal error |
| Current Output: |
- Overflow |
| 4-20 mA (Isolated) |
- Empty pipe |
| Load |
Cable Entry: |
Max. 600  |
Standard :M20 / PG11 Option:1/2"NPTF |
| Pulse output: |
Protection Class: |
| Open collector |
IP 67, Explosion proof, Exd(ib)ibqllBT5 |
| Rating |
Ambient Temperature: |
| 3 to 30 Vdc, 20 mA Max. |
|
| Pulse Rate: |
Material: |
| 1)Scale pulse (Pusle/M3, Pulse/L, Other) |
Aluminum Alloy |
| 2)Frequency: 0-5000 Hz |
Power Supply: |
| Pulse Width: |
90-260 Vac, 50/60 Hz |
| 50% of band width |
24Vdc +/-10% (Option) |
| Alarm: |
Power Consumption: |
| High/Low with open collector output |
3-17 W (Dependent on sensor size) |
| Rating |
Weight: |
| 3 to 30 Vdc, 20 mA Max. |
4.5 Kg |
| Communication: |
Mounting: |
| RS 485 (MODBUS Protocol) |
Wall mounting |
| HART signal |
Bracket on 2" pipe |
| Data Storage: |
|
| Operation parameters and totalizer |
|
| figures are stored by EEPROM for more |
|
than 10 years
|
