| FEATURES |
| |
|
 Large 2-line LCD with backlit display
Sources and reads mA, mV, V, Ohms, RTD and frequency
Keypad to enter output parameters directly
Simultaneous millivolt display when in temperature measurement mode
Small, streamlined shape, easy to carry and hold
Thermocouple measurement/output with automatic or manual cold junction compensation
Quick query to resistance & temperature, and millivolt & temperature
24VDC loop power supply
Ni-MH battery available, continuous use for at least 6 hours
Concurrent input/output, convenient to operate
|
| |
| SPECIFICATION |
| |
| Source: |
Battery Type: |
| VDC, mA, mV |
NiMH Pack, 1800 mAh, 7.2VDC |
| T/C(S, K, E, T, J, B, R, N, W325) |
Charger Supply: |
| Frequency, 0-5000 Hz (4VDC) |
90 ~ 260VAC 50/60 Hz |
Resistance, 10  - 5000 |
Power Consumptio: |
| 24VDC, 30mA Max. |
2W |
| Read: |
Accessory Included: |
| VDC, mA, mV |
Test leads two pairs |
| T/C(S, K, E, T, J, B, R, N, W325) |
Power Adaptor(90-265VAC, 50/60Hz) |
| Frequency, 0-5000 Hz (24 VDC Max.) |
Reinforced aluminum carrying case |
| RTD(PT100 , Cu50) |
Shoulder straps for carrying case only |
| Response Time: |
Dimension: |
| 80ms |
Calibrator |
| Operating Temp.: |
231 *104 * 39mm |
| -10 ~ +55 oC |
9.1" * 4.1" * 1.5" |
| Ambient Humidity: |
Carrying Case |
| 0 - 90% RH non-condensing |
330 * 250 * 150mm |
| Display: |
13" * 9.8" * 6.0" |
| 2" (128*64 Pixels), Backlight LCD |
Weight: |
| Display Update Rate: |
0.7 Kg |
| 4 / second |
Enclosure: |
| Keyboard: |
IP54 |
| 25 Membrane keyboard |
|
| Password Protection: |
|
| 4 Digits |
|
| Battery Operation: |
|
| 6-8 Hours |
|
| Charge Time: |
|
| 8-12 Hours |
|
